pmap_piece()
operates on the rows of a data frame
applying .f
to each row (usually grid.piece
).
A list of vectors, such as a data frame. The length of .l
determines the number of arguments that .f
will be called with. List names will be used if present.
Function to be applied to .l
after adjustments to
cfg
and envir
and the application of trans
.
Usually grid.piece()
, pieceGrob()
, piece3d()
, or piece()
.
Extra arguments to pass to .f
.
Piecepack configuration list or pp_cfg
object,
a list of pp_cfg
objects,
or a character vector referring to names in envir
or a character vector referring to object names that
can be retrieved by base::dynGet()
.
Environment (or named list) containing configuration list(s).
Function to modify .l
before drawing.
Default (NULL
) is to not modify .l
. op_transform
can help with using an oblique projection (i.e. op_scale
over 0).
A logical value indicating whether graphics output should be produced.
A character identifier (for grid)
An object of class “gpar”.
A grid
viewport object (or NULL
).
pmap_piece()
differs from purrr::pmap()
in a few ways:
If cfg
and/or envir
are missing attempts to set reasonable defaults.
If not NULL
will first apply function trans
to .l
.
If the output of .f
is a grid grob object then pmap_piece
will return a gTree
object with
specified name
, gp
, and vp
values and if draw
is true draw it.
If .l
lacks a name
column or if name
column is non-unique
attempts to generate a reasonable new default name
column
and use that to name the return gTree
children or list
values.
render_piece()
is a higher-level function that wraps this function.
if (requireNamespace("grid", quietly = TRUE) && piecepackr:::device_supports_unicode()) {
dark_colorscheme <- list(suit_color="darkred,black,darkgreen,darkblue,black",
invert_colors.suited=TRUE, border_color="black", border_lex=2)
traditional_ranks <- list(use_suit_as_ace=TRUE, rank_text=",a,2,3,4,5")
cfg3d <- list(width.pawn=0.75, height.pawn=0.75, depth.pawn=1,
dm_text.pawn="", shape.pawn="convex6", invert_colors.pawn=TRUE,
edge_color.coin="tan", edge_color.tile="tan")
cfg <- pp_cfg(c(dark_colorscheme, traditional_ranks, cfg3d))
grid::grid.newpage()
df_tiles <- data.frame(piece_side="tile_back", x=0.5+c(3,1,3,1), y=0.5+c(3,3,1,1),
suit=NA, angle=NA, z=NA, stringsAsFactors=FALSE)
df_coins <- data.frame(piece_side="coin_back", x=rep(4:1, 4), y=rep(4:1, each=4),
suit=1:16%%2+rep(c(1,3), each=8),
angle=rep(c(180,0), each=8), z=1/4+1/16, stringsAsFactors=FALSE)
df <- rbind(df_tiles, df_coins)
pmap_piece(df, cfg=cfg, op_scale=0.5, default.units="in")
}
