Generate chess boards and pieces

Source: R/chess_boards.r
chess_pieces.Rd

chess_board() returns a square checkered board of desired size and type. chess_bits() returns chess pieces.

Usage

chess_board(
  nrows = 8L,
  ncols = nrows,
  x0 = 1,
  y0 = 1,
  ...,
  side = "face",
  piece_side = paste0("board_", side),
  suit = "green",
  angle = 0,
  cell_width = getOption("ppdf.chess_cell_width", 1)
)

chess_bits(
  ...,
  suit = rep(1:6, each = 6L),
  rank = rep(1:6, 6L),
  x = rep(1:6, 6L),
  y = rep(1:6, each = 6L),
  angle = 0,
  cell_width = getOption("ppdf.chess_cell_width", 1),
  length.out = NA_integer_
)

Arguments

nrows

Number of rows in game board

ncols

Number of columns in game board

x0

X coordinate for the center of the first cell

y0

Y coordinate for the center of the first cell

...

Should be left empty.

side

Either "face" or "back"

piece_side

If "board_face" a checkered board (as in American Checkers). If "board_back" a lined board (as in Turkish Checkers).

suit

Suit value (color) of board and pieces. 1L is "red", 2L is "black", 3L is "green", 4L is "blue", 5L is "yellow", and 6L is "white". Will be coerced by piece_suit().

angle

Rotation of bit/board (numeric vector of degrees, counter-clockwise). Will be coerced by piece_angle().

cell_width

Width of board cell. piecepackr::game_systems() supports 1 or 2.

rank

Rank value of chess pieces from 1L (pawn) to 6L (king). Will be coerced by chess_rank().

x, y

Cartesian coordinates (numeric vectors)

length.out

The number of pieces. Not needed if all the arguments are the same length (or of length one) and this length is the same as the number of desired pieces.

Value

A tibble::tibble() data frame with the following columns:

  • "piece_side"

  • "suit"

  • "rank"

  • "cfg" (optional, defaults to "piecepack")

  • "x"

  • "y"

  • "angle" (optional, defaults to 0).

This data frame is compatible with piecepackr::render_piece() and likely ppcli::cat_piece().

Examples

# David Silverman's "Mini chess 4x4"
dfb <- chess_board(nrows = 4L, ncol = 4L)
df1 <- chess_bits(suit = "white", rank = c("R", "Q", "K", "R"),
                  x = 1:4, y= 1)
df2 <- chess_bits(suit = "white", rank = "P", x = 1:4, y= 2)
df3 <- chess_bits(suit = "black", rank = "P", x = 1:4, y= 3)
df4 <- chess_bits(suit = "black", rank = c("r", "q", "k", "r"),
                  x = 1:4, y= 4)
df <- rbind(dfb, df1, df2, df3, df4)
if (require("piecepackr", quietly = TRUE) &&
    packageVersion("piecepackr") >= "1.15.0-1" &&
    requireNamespace("systemfonts", quietly = TRUE) &&
    piecepackr::has_font("Dejavu Sans") &&
    piecepackr:::device_supports_unicode()) {
  grid::grid.newpage()
  envir = game_systems("dejavu")
  pmap_piece(df, envir = envir, default.units = "in")
}
